Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
Menu 7
Commander SK Advanced User Guide 83
Issue Number: 2 www.controltechniques.com
This parameter is used to scale the analog input if so desired. However in most cases it is not necessary as each input is automatically scaled such
that for 100.0%, the destination parameters (defined by the settings of Pr 7.10 and Pr 7.14) will be at maximum.
This parameter can be used to invert the analog input reference (i.e. multiply the input scaling result by -1).
As default, this parameter is set-up automatically according to the drive configuration (see Pr 11.27 on page 116).
Only non bit parameters which are not protected can be controlled by analog inputs. If a non valid parameter is programmed to the destination of an
analog input, the input is not routed anywhere.
After a modification to this parameter, the destination is only changed when a reset is performed.
Analog input 2 can be configured as either a 0 to +10V analog input or a +24V digital input (positive logic).
When analog input 2 is set up for analog input, this parameter is used to scale the input (see Pr 7.08). When the input is defined as a digital input, this
parameter has no effect.
7.08 Analog input 1 scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range 0.000 to 4.000
Default 1.000
Update rate Background
7.09 Analog input 1 invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 or 1
Default 0
Update rate 5 ms
7.10 Analog input 1 destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 1.01 to Pr 21.51
Default Pr 1.36
Update rate Read on drive reset
7.11 Analog input 2 mode (terminal T4)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range 0 to 1
Default 0
Update rate Background
Value Display Function
0 VoLt 0 to +10V
1 dig 0 to +24V
7.12 Analog input 2 scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range 0.000 to 4.000
Default 1.000
Update rate Background
