These bits are provided for control by logic input terminals for external reference selection (see Pr 1.14 on page 26, and Pr 1.15 on page 27).
Pr 1.41 Analog reference 2 select (lowest priority)
Pr 1.42 Preset reference select
Pr 1.43 Keypad reference select
Pr 1.44 Precision reference select (highest priority)
If more than one of these parameters is active, the highest priority take precedence.
Indicates the reference currently being selected.
1: Analog reference 1 selected
2: Analog reference 2 selected
3: Preset reference selected
4: Keypad reference selected
5: precision reference selected
Indicates the preset currently being selected. If Pr 1.49 = 1 or 2 then a value of 1 indicates that one of the analog references is being selected.
Selects the value of the keypad reference on power-up.
Value Display Function
0 0 keypad reference is zero
1 LASt keypad reference is the last used value
2 PrS1 keypad reference is copied from Preset speed 1 (Pr 1.21)
1.41 Analog reference 2 select
1.42 Preset reference select
1.43 Keypad reference select
1.44 Precision reference select
1.45 Preset select bit 0
1.46 Preset select bit 1
1.47 Preset select bit 2
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default 0
Update rate 5ms
1.48 Unused parameter
1.49 Reference selected indicator
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range 1 to 5
Update rate 5ms
1.50 Preset reference selected indicator
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range 1 to 8
Update rate 5ms
1.51 Power-up keypad reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0 to 2
Default 0
Update rate N/A
