This source parameter and Pr 9.04 define the inputs for source 1 of the programmable logic functions.
Only bit parameters can be programmed into these inputs.
If one or both inputs to the logic function are invalid, then the logic output will always be 0.
Setting this parameter and Pr 9.05 to a 1 causes the input sense of the logic functions to be inverted.
This source parameter and Pr 9.06 defines the inputs for source 2 of the programmable logic functions.
Only bit parameters can be programmed into these inputs.
If one or both inputs to the logic function are invalid, then the logic output will always be 0.
Setting this parameter and Pr 9.07 to a 1 causes the input sense of the logic functions to be inverted.
Setting this parameter and Pr 9.08 to a 1 causes the output sense from the logic functions to be inverted.
If the delay parameter is positive, the delay ensures that the output does not become active until an active condition has been present at the input for
9.14 Logic function 2 source 1
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range Pr 0.01 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
9.15 Logic function 2 source 1 invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 or 1
Default 0
Update rate 21 ms
9.16 Logic function 2 source 2
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range Pr 0.01 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
9.17 Logic function 2 source 2 invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 or 1
Default 0
Update rate 21 ms
9.18 Logic function 2 output invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 or 1
Default 0
Update rate 21 ms
9.19 Logic function 2 delay
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range ±25.0 s
Default 0.0
Update rate 21 ms
