9.2 Menu 1: Speed reference selection, limits and filters
Table 9-3 Menu 1 parameters: single line descriptions
* The maximum value is Pr 1.06 or Pr 21.01
Parameter Range Default Setting Update Rate
1.01 Frequency reference selected ± 1500.0 Hz*
5 ms
1.02 Pre-skip filter reference ± 1500.0 Hz
5 ms
1.03 Pre-ramp reference ± 1500.0 Hz
5 ms
1.04 Reference offset ± 1500.0 Hz 0.0 5 ms
1.05 Jog reference {15} 0.0 to 400.0 Hz 1.5 5 ms
1.06 Maximum set speed {02} 0.0 to 1500.0 Hz
50(EUR)
60(USA)
B
1.07 Minimum set speed {01} 0.0 to Pr 1.06 0.0 B
1.08 Not used
1.09 Reference offset select 0 or 1 0 5 ms
1.10 Allow negative references {17}0 or 1 0 B
1.11 Reference enabled indicator 0 or 1
2 ms
1.12 Reverse selected indicator 0 or 1
2 ms
1.13 Jog selected indicator 0 or 1
2 ms
1.14 Reference selector 0 to 5 0 5 ms
1.15 Preset selector 0 to 8 0 5 ms
1.16 Not used
1.17 Keypad control mode reference ± 1500.0 Hz 0.0 B
1.18 Precision reference coarse ± 1500.0 Hz 0.0 5 ms
1.19 Precision reference fine 0.000 to 0.099 Hz 0.000 5 ms
1.20 Precision reference update disable 0 or 1 0 5 ms
1.21 Preset speed 1 {18} ± 1500.0 Hz 0.0 5 ms
1.22 Preset speed 2 {19} ± 1500.0 Hz 0.0 5 ms
1.23 Preset speed 3 {20} ± 1500.0 Hz 0.0 5 ms
1.24 Preset speed 4 {21} ± 1500.0 Hz 0.0 5 ms
1.25 Preset speed 5 ± 1500.0 Hz 0.0 5 ms
1.26 Preset speed 6 ± 1500.0 Hz 0.0 5 ms
1.27 Preset speed 7 ± 1500.0 Hz 0.0 5 ms
1.28 Preset speed 8 ± 1500.0 Hz 0.0 5 ms
1.29 Skip reference 1 0.0 to 1500.0 Hz 0.0 B
1.30 Skip reference band 1 0.0 to 25 Hz 0.5 B
1.31 Skip reference 2 0.0 to 1500.0 Hz 0.0 B
1.32 Skip reference band 2 0.0 to 25 Hz 0.5 B
1.33 Skip reference 3 0.0 to 1500.0 Hz 0.0 B
1.34 Skip reference band 3 0.0 to 25 Hz 0.5 B
1.35 Reference in rejection zone 0 or 1
5 ms
1.36 Analog reference 1 ± 1500.0 Hz*
5 ms
1.37 Analog reference 2 ± 1500.0 Hz*
5 ms
1.38 Percentage trim ±100.0% 0.0 5 ms
1.39 Not used
1.40 Not used
1.41 Analog reference 2 select 0 or 1 0 5 ms
1.42 Preset reference select 0 or 1 0 5 ms
1.43 Keypad reference select 0 or 1 0 5 ms
1.44 Precision reference select 0 or 1 0 5 ms
1.45 Preset select bit 0 0 or 1 0 5 ms
1.46 Preset select bit 1 0 or 1 0 5 ms
1.47 Preset select bit 2 0 or 1 0 5 ms
1.48 Not used
1.49 Reference selected indicator 1 to 5 5 ms
1.50 Preset Reference selected indicator 1 to 8
5 ms
1.51 Power up keypad control reference {27} 0 to 2 0 N/A
