Control Techniques Commander SK User Manual

Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
Menu 15
Commander SK Advanced User Guide 151
Issue Number: 2 www.controltechniques.com
Destination parameters define the parameter each of the programmable inputs is to control. Only bit parameters that are not protected can be
controlled by the programmable digital inputs. If a non-valid parameter is programmed, the digital input is not routed anywhere.
This parameter defines the parameter to be represented by the status relay. Only bit parameters can be selected as a source for the relay output. If a
non-valid parameter is programmed, then the relay will remain in the de-energised state.
This parameter shows the encoder speed in rpm provided that the set-up parameters for the drives encoder are correct.
0: Real time clock parameters controlled by real time clock
1: Real time clock parameters controlled by user
2: Real time clock reads real time clock parameters and sets Pr 15.30 to 0
0: 512 lines per revolution encoder
1: 1024 lines per revolution encoder
2: 2048 lines per revolution encoder
3: 4096 lines per revolution encoder
A change to this parameter only takes effect when the drive is disabled, stopped or tripped.
15.24 Terminal T5 digital input destination
15.25 Terminal T6 digital input destination
15.26 Terminal T7 digital input destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 1.01 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
15.27 Terminal T21/T23 relay source
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 0.01 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
15.28 Unused parameter
15.29 Drive encoder speed feedback
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range -32000 to + 32000 rpm
Update rate Background write
15.30 Real time clock update mode
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11
Range 0 to 2
Default 0
Update rate Background read/write
15.31 Drive encoder lines per revolution
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range 0 to 3
Default 1
Update rate Background read
NOTE
