This parameter monitors the reference input of the PID controller.
This parameter monitors the feedback input of the PID controller.
This parameter monitors the error of the PID controller.
14.20 PID reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range ±100.0 %
Update rate 21 ms
14.21 PID feedback
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range ±100.0 %
Update rate 21 ms
14.22 PID error
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range ±100.0 %
Update rate 21 ms
