Menu 15 Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
152 Commander SK Advanced User Guide
www.controltechniques.com Issue Number: 2
When an option with a real time clock is fitted, Pr 15.34 to Pr 15.37 will be controlled by the option.
Terminal T2 is a voltage/current reference input. The setting of this parameter configures the terminal for the required mode.
15.32 Drive encoder revolution counter
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111 1
Range 0 to 65535 revolutions
Update rate Background write
15.33 Drive encoder position
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111 1
Range
0 to 65535 (1/2
16
ths of a revolution)
Update rate Background write
15.34 Real time clock minutes/seconds
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2111
Range 00.00
Default 00.00 to 59.59
Update rate Background read/write
15.35 Real time clock days/hours
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2111
Range 00.0
Default 1.00 to 7.23
Update rate Background read/write
15.36 Real time clock month date
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2111
Range 00.00
Default 00.00 to 12.31
Update rate Background read/write
15.37 Real time clock years
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 2000
Default 2000 to 2099
Update rate Background read/write
15.38 Analog input 1 mode (Terminal T2)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 6
Default 0
Update rate Background read
