9.15 Menu 15: I/O Option parameters
Table 9-20 Menu 15 parameters: single line descriptions
Parameter Range Default Setting Update Rate
15.01 Not used
15.02 Not used
15.03 Current loop loss indicator 0 or 1 BW
15.04 Terminal T5 digital input state
0 or 1 BW
15.05 Terminal T6 digital input state
0 or 1 BW
15.06 Terminal T7 digital input state
0 or 1 BW
15.07 Relay state (Terminals T21 and T23)
0 or 1 BW
15.08 Not used
15.09 Not used
15.10 Not used
15.11 Not used
15.12 Not used
15.13 Not used
15.14 Terminal T5 digital input invert 0 to 1 0 BR
15.15 Terminal T6 digital input invert
0 to 1 0 BR
15.16 Terminal T7 digital input invert
0 to 1 0 BR
15.17 Relay invert
0 to 1 0 BR
15.18 Not used
15.19 Real time clock day light saving mode 0 to 1 0 BR
15.20 Digital I/O read word
0 to 255 BW
15.21 Not used
15.22 Not used
15.23 Not used
15.24 Terminal T5 digital input destination Pr 1.01 to Pr 21.51 Pr 0.00 Drive reset
15.25 Terminal T6 digital input destination
Pr 1.01 to Pr 21.51 Pr 0.00 Drive reset
15.26 Terminal T7 digital input destination
Pr 1.01 to Pr 21.51 Pr 0.00 Drive reset
15.27 Terminal T21/T23 relay source
Pr 0.01 to Pr 21.51 Pr 0.00 Drive reset
15.28 Not used
15.29 Drive encoder speed feedback -32000 to +32000 rpm BW
15.30 Real time clock update mode
0 to 2 0 B R/W
15.31 Drive encoder lines per revolution
0 to 3 1 BR
15.32 Drive encoder revolution counter
0 to 65535 BW
15.33 Drive encoder position
0 to 65535 (1/2
16
ths of a
revolution)
BW
15.34 Real time clock minutes/seconds
00.00 to 59.59 00.00 B R/W
15.35 Real time clock days/hours
1.00 to 7.23 0.00 B R/W
15.36 Real time clock month date
00.00 to 12.31 00.00 B R/W
15.37 Real time clock years
2000 to 2099 2000 B R/W
15.38 Analog input 1 mode (Terminal T2)
0 to 6 0 BR
15.39 Analog output 1 mode (Terminal T3)
0 to 4 0 BR
15.40 Analog input 1 monitor (Terminal T2)
-100% to +100% BW
15.41 Analog input 1 scaling (Terminal T2)
0.000 to 4.000 1.000 BR
15.42 Analog input 1 invert (Terminal T2)
0 to 1 0 BR
15.43 Analog input 1 destination (Terminal T2)
Pr 1.01 to Pr 21.51 Pr 0.00 Drive reset
15.44 Maximum drive encoder reference
0 to 32000 rpm 1500 BR
15.45 Drive encoder reference scaling
0.000 to 4.000 1.000 BR
15.46 Drive encoder reference monitor
-100% to +100% BW
15.47 Drive encoder reference destination
Pr 1.01 to Pr 21.51 Pr 0.00 Drive reset
15.48 Analog output 1 source (Terminal T3)
Pr 0.01 to Pr 21.51 Pr 0.00 Drive reset
15.49 Analog output 1 scaling (Terminal T3)
0.000 to 4.000 1.000 BR
