54 Commander SK Advanced User Guide
www.controltechniques.com Issue Number: 2
0: Ld Value of Pr 4.20 displayed.
1: A Value of Pr 4.01 displayed.
This parameter defines whether the load indication in the display status mode displays percentage load or output current
The maximum for Pr 4.08 and Pr 4.20 is defined by this parameter.
0: Low speed thermal protection mode disabled
1: Low speed thermal protection mode enabled
See Pr 4.16 on page 51 for details.
Pr 4.26 shows the torque producing current (Pr 4.02) as a percentage of the active torque producing current, but with an additional adjustment above
base speed so that this parameter shows percentage torque. Below base speed, Pr 4.26 is equal to Pr 4.20. Above base speed the percentage
torque producing current (Pr 4.20) is adjusted as follows:
Pr 4.26 = Pr 4.20 x motor rated frequency (Pr 5.06) /post ramp reference (Pr 2.01)
4.21 Load display units
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0 to 1
Update rate Background
4.22 to 4.23 Unused parameters
4.24 User current maximum scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 111
Range 0.0 to TORQUE_PROD_CURRENT_MAX %
Default 165.0
Update rate Background
4.25 Low speed thermal protection mode
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 or 1
Default 0
Update rate Background
4.26 Percentage torque
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 11111
Range ±USER_CURRENT_MAX %
Update rate Background
