Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
Menu 8
Commander SK Advanced User Guide 87
Issue Number: 2 www.controltechniques.com
9.9 Menu 8: Digital inputs and outputs
Table 9-10 Menu 8 parameters: single line descriptions
Parameter Range Default Setting Update Rate
8.01 Terminal B3 digital input/output state 0 or 1
2 ms
8.02 Terminal B4 digital input state 0 or 1
2 ms
8.03 Terminal B5 digital input state 0 or 1
2 ms
8.04 Terminal B6 digital input state 0 or 1
2 ms
8.05 Terminal B7 digital input state 0 or 1
2 ms
8.06 Not used
8.07 Status relay state (Terminals T5 & T6) 0 or 1 2 ms
8.08 Not used
8.09 Not used
8.10 Not used
8.11 Terminal B3 digital input/output invert 0 or 1 0 2 ms
8.12 Terminal B4 digital input invert 0 or 1 0 2 ms
8.13 Terminal B5 digital input invert 0 or 1 0 2 ms
8.14 Terminal B6 digital input invert 0 or 1 0 2 ms
8.15 Terminal B7 digital input invert 0 or 1 1 2 ms
8.16 Not used
8.17 Status relay invert 0 or 1 0 2 ms
8.18 Not used
8.19 Not used
8.20 Digital I/O read word 0 to 95 B
8.21
Terminal B3 digital input destination/output
source
Pr 0.01 to 21.51 Pr 10.03 Drive reset
8.22 Terminal B4 digital input destination Pr 1.01 to 21.51 Pr 6.29 Drive reset
8.23 Terminal B5 digital input destination Pr 1.01 to 21.51 Pr 6.30 Drive reset
8.24 Terminal B6 digital input destination Pr 1.01 to 21.51 Pr 6.32 Drive reset
8.25 Terminal B7 digital input destination Pr 1.01 to 21.51 Pr 1.41 Drive reset
8.26 Not used
8.27 Status relay source Pr 0.01 to 21.51 Pr 10.01 Drive reset
8.28 Not used
8.29 Not used
8.30 Not used
8.31 Terminal B3 function select 0 to 3 1 B
8.32 Not used
8.33 Not used
8.34 Not used
8.35 Terminal B7 function select {34} 0 to 3 0 B
8.36 Not used
8.37 Not used
8.38 Not used
8.39 Not used
8.40 Not used
8.41 Digital output control (Terminal B3) {35} 0 to 8 0 Drive reset
