9.12 Menu 11: General drive set-up
Table 9-17 Menu 11 parameters: single line descriptions
Parameter Range Default Setting Update Rate
11.01 Pr 61 set-up {61}Pr 0.00 to Pr 21.51 Pr 0.00 B
11.02 Pr 62 set-up {62}Pr 0.00 to Pr 21.51 Pr 0.00 B
11.03 Pr 63 set-up {63}Pr 0.00 to Pr 21.51 Pr 0.00 B
11.04 Pr 64 set-up {64}Pr 0.00 to Pr 21.51 Pr 0.00 B
11.05 Pr 65 set-up {65}Pr 0.00 to Pr 21.51 Pr 0.00 B
11.06 Pr 66 set-up {66}Pr 0.00 to Pr 21.51 Pr 0.00 B
11.07 Pr 67 set-up {67}Pr 0.00 to Pr 21.51 Pr 0.00 B
11.08 Pr 68 set-up {68}Pr 0.00 to Pr 21.51 Pr 0.00 B
11.09 Pr 69 set-up {69}Pr 0.00 to Pr 21.51 Pr 0.00 B
11.10 Pr 70 set-up {70}Pr 0.00 to Pr 21.51 Pr 0.00 B
11.11 Not used
11.12 Not used
11.13 Not used
11.14 Not used
11.15 Not used
11.16 Not used
11.17 Not used
11.18 Not used
11.19 Not used
11.20 Not used
11.21 Parameter scaling {24} 0.000 to 9.999 1.000 B
11.22 Parameter displayed at power up 0 or 1 0 N/A
11.23 Serial address {44} 0 to 247 1 B
11.24 Modbus RTU / user serial mode 0 to 3 1 B
11.25 Baud rate {43} 0 to 4 3 B
11.26 Silent period extension 0 to 250 ms 2 B
11.27 Drive configuration {05} 0 to 8 0 Drive reset
11.28 Not used
11.29 Software version {45} 0.00 to 99.99 N/A
11.30 User security code {25} 0 to 999
B
11.31 Not used
11.32 Maximum heavy duty drive current rating 0.00 to 290.00 A N/A
11.33 Voltage rating 0 to 2
N/A
11.34 Software sub-version 0 to 99
N/A
11.35 DSP software version 0.0 to9.9
N/A
11.36 Not used
11.37 Not used
11.38 Not used
11.39 Not used
11.40 Not used
11.41 Status mode timeout 0 to 250 s 240 B
11.42 Parameter cloning {28} 0 to 4 0 Drive reset
11.43 Load defaults {29} 0 to 3 0 Drive reset
11.44 Security status {10} 0 to 3 0 Drive reset
11.45 Select motor 2 parameters 0 or 1 0 B
11.46 Defaults previously loaded 0 to 2 0 BW
11.47 Drive user program enable 0 to 2 2 BR
11.48 Drive user program status -128 to 127
BW
11.49 Not used
11.50 User program maximum scan time 0 to 65535 ms User program
