Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
Menu 15
Commander SK Advanced User Guide 155
Issue Number: 2 www.controltechniques.com
The parameter required to be represented as an analog signal by the analog output on Terminal T3 should be programmed in this parameter. Only
non-bit parameters that are not protected can be programmed as a source. If a non-valid parameter is programmed as a source, the output will
remain at zero. After a modification to this parameter, the source is only changed when a reset is performed.
This parameter can be used to scale the analog output if so desired. However in most cases it is not necessary as the output is automatically scaled
such that when the source parameter is at its maximum, the analog output will be at its maximum.
15.48 Analog output 1 source (Terminal T3)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range Pr 0.01 to Pr 21.51
Default Pr 0.00
Update rate Drive read on reset
15.49 Analog output 1 scaling (Terminal T3)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range 0.000 to 4.000
Default 1.000
Update rate Background read
