Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
Menu 21
Commander SK Advanced User Guide 159
Issue Number: 2 www.controltechniques.com
9.18 Menu 21: Second motor map
Table 9-23 Menu 21 parameters: single line descriptions
Parameter Range Default Setting Update Rate
21.01 Motor 2 maximum set speed 0.0 to 1500.0 Hz 50(EUR), 60(USA)
B
21.02 Motor 2 minimum set speed 0.0 to Pr 1.06 0.0
B
21.03 Motor 2 reference selector 0 to 5 0
5 ms
21.04 Motor 2 acceleration rate 0.0 to 3200.0 s/100 Hz 5.0
5 ms
21.05 Motor 2 deceleration rate 0.0 to 3200.0 s/100 Hz 10.0
5 ms
21.06 Motor 2 motor rated frequency 0.0 to 1500.0 Hz 50.0(EUR), 60.0(USA)
B
21.07 Motor 2 motor rated current
0 to RATED_
CURRENT_MAX A
Drive rated current
{Pr 11.32}
B
21.08 Motor 2 motor rated load rpm 0 to 9999 rpm 1500(EUR), 1800(USA)
B
21.09 Motor 2 motor rated voltage
0 to AC_VOLTAGE_SET_
MAX V
200 V drive: 230
400 V drive: 400(EUR)
460(USA)
128 ms
21.10 Motor 2 motor rated power factor 0.00 to 1.00 0.85
B
21.11 Motor 2 number of poles 0 to 4 0
B
21.12 Motor 2 stator resistance 0.000 to 30.000
0.000 B
21.13 Motor 2 voltage offset 0.0 to 25.0 V 0.0
B
21.14
Motor 2 transient inductance (
σL
s
)
0.000 to 320.00 mH 0.000
B
21.15 Motor 2 active 0 to 1 0
B
21.16 Motor 2 thermal time constant 0 to 250 89
B
21.17 Not used
21.18 Not used
21.19 Not used
21.20 Not used
21.21 Not used
21.22 Not used
21.23 Not used
21.24 Not used
21.25 Not used
21.26 Not used
21.27 Not used
21.28 Not used
21.29 Motor 2 symmetrical current limit
0 to
MOTOR2_CURRENT_LIMIT_
MAX %
165.0 B
