Control Techniques Commander SK User Manual

Menu 9 Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
94 Commander SK Advanced User Guide
www.controltechniques.com Issue Number: 2
9.10 Menu 9: Programmable logic, motorised pot and binary sum
Table 9-11 Menu 9 parameters: single line descriptions
Parameter Range Default Setting Update Rate
9.01 Logic function 1 output 0 or 1
21 ms
9.02 Logic function 2 output 0 or 1
21 ms
9.03 Motorised pot output
±100.0% 21 ms
9.04 Logic function 1 source 1 Pr 0.01 to Pr 21.51 Pr 0.00
Drive reset
9.05 Logic function 1 source 1 invert 0 or 1 0
21 ms
9.06 Logic function 1 source 2 Pr 0.01 to Pr 21.51 Pr 0.00
Reset
9.07 Logic function 1 source 2 invert 0 or 1 0
21 ms
9.08 Logic function 1 output invert 0 or 1 0
21 ms
9.09 Logic function 1 delay
±25.0 s 0.0 21 ms
9.10 Logic function 1 destination Pr 1.01 to Pr 21.51 Pr 0.00
Drive reset
9.11 Not used
9.12 Not used
9.13 Not used
9.14 Logic function 2 source 1 Pr 0.01 to Pr 21.51 Pr 0.00 Drive reset
9.15 Logic function 2 source 1 invert 0 or 1 0
21 ms
9.16 Logic function 2 source 2 Pr 0.01 to Pr 21.51 Pr 0.00
Drive reset
9.17 Logic function 2 source 2 invert 0 or 1 0
21 ms
9.18 Logic function 2 output invert 0 or 1 0
21 ms
9.19 Logic function 2 delay
±25.0 s 0.0 21 ms
9.20 Logic function 2 destination Pr 1.01 to Pr 21.51 Pr 0.00
Drive reset
9.21 Motorised pot mode 0 to 3 2
BR
9.22 Motorised pot Bipolar select 0 or 1 0
21 ms
9.23 Motorised pot rate 0 to 250 s 20
B
9.24 Motorised pot scale factor 0.000 to 4.000 1.000
B
9.25 Motorised pot destination Pr 1.01 to Pr 21.51 Pr 0.00
Drive reset
9.26 Motorised pot up 0 or 1
21 ms
9.27 Motorised pot down 0 or 1
21 ms
9.28 Motorised pot reset 0 or 1
21 ms
9.29 Binary sum one’s input 0 or 1 0
21 ms
9.30 Binary sum two’s input 0 or 1 0
21 ms
9.31 Binary sum four’s input 0 or 1 0
21 ms
9.32 Binary sum output 0 to 255
21 ms
9.33 Binary sum destination Pr 1.01 to Pr 21.51 Pr 0.00
Drive reset
9.34 Binary sum offset 0 to 248 0
21 ms
