9.3 Menu 2: Ramps
Table 9-4 Menu 2 parameters: single line descriptions
Parameter Range Default Setting Update Rate
2.01 Post ramp reference ± 1500.0 Hz
21 ms
2.02 Not used
2.03 Ramp hold 0 or 1 0 128 ms
2.04 Ramp mode select {30} 0 to 3 1 B
2.05 Not used
2.06 S ramp enable 0 or 1 0 B
2.07 S ramp acceleration limit
0.0 to 300.0 s
2
/100 Hz
3.1 B
2.08 Standard ramp voltage
0 to DC_VOLTAGE_SET_MAX V
200 V drive: 375
400 V drive: 750 (EUR)
775 (USA)
B
2.09 Not used
2.10 Acceleration rate selector 0 to 9 0 5 ms
2.11 Acceleration rate 1 {03} 0.0 to 3200.0 s/100 Hz 5.0 5 ms
2.12 Acceleration rate 2
0.0 to 3200.0 s
/100 Hz
5.0 5 ms
2.13 Acceleration rate 3
0.0 to 3200.0 s
/100 Hz
5.0 5 ms
2.14 Acceleration rate 4
0.0 to 3200.0 s
/100 Hz
5.0 5 ms
2.15 Acceleration rate 5
0.0 to 3200.0 s
/100 Hz
5.0 5 ms
2.16 Acceleration rate 6
0.0 to 3200.0 s
/100 Hz
5.0 5 ms
2.17 Acceleration rate 7
0.0 to 3200.0 s
/100 Hz
5.0 5 ms
2.18 Acceleration rate 8
0.0 to 3200.0 s
/100 Hz
5.0 5 ms
2.19 Jog acceleration rate
0.0 to 3200.0 s
/100 Hz
0.2 5 ms
2.20 Deceleration rate selector 0 to 9 0 5 ms
2.21 Deceleration rate 1 {04}
0.0 to 3200.0 s
/100 Hz
10.0 5 ms
2.22 Deceleration rate 2
0.0 to 3200.0 s
/100 Hz
10.0 5 ms
2.23 Deceleration rate 3
0.0 to 3200.0 s
/100 Hz
10.0 5 ms
2.24 Deceleration rate 4
0.0 to 3200.0 s
/100 Hz
10.0 5 ms
2.25 Deceleration rate 5
0.0 to 3200.0 s
/100 Hz
10.0 5 ms
2.26 Deceleration rate 6
0.0 to 3200.0 s
/100 Hz
10.0 5 ms
2.27 Deceleration rate 7
0.0 to 3200.0 s
/100 Hz
10.0 5 ms
2.28 Deceleration rate 8
0.0 to 3200.0 s
/100 Hz
10.0 5 ms
2.29 Jog deceleration rate
0.0 to 3200.0 s
/100 Hz
0.2 5 ms
2.30 Acceleration selected indicator
1 to 8 1 5 ms
2.31 Acceleration selected indicator
1 to 8 1 5 ms
2.32 Acceleration select bit 0 0 or 1 0 5 ms
2.33 Acceleration select bit 1 0 or 1 0 5 ms
2.34 Acceleration select bit 2 0 or 1 0 5 ms
2.35 Deceleration select bit 0 0 or 1 0 5 ms
2.36 Deceleration select bit 1 0 or 1 0 5 ms
2.37 Deceleration select bit 2 0 or 1 0 5 ms
2.38 Not used
2.39 Ramp rate units 0 or 2 1 B
