Setting these parameters to a 1 causes the input sense to the destination parameter to be inverted.
Setting this parameter to a 1 causes the relay sense to be inverted.
0 Real time clock normal operation
1 Real time clock + 1 hour
This word is used to determine the status of the digital I/O by reading one parameter.
Pr 15.20 contains a binary value 'xx'. This binary value is determined by the state of Pr 15.04 to Pr 15.07. So for example, if all terminals were active
the value displayed in Pr 15.20 would be the sum of the binary values shown in the table, i.e. 120.
15.14 Terminal T5 digital input invert
15.15 Terminal T6 digital input invert
15.16 Terminal T7 digital input invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 1
Default 0
Update rate Background read
15.17 Relay invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 1
Default 0
Update rate Background read
15.18 Unused parameter
15.19 Real time clock day light saving mode
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 1
Default 0
Update rate Background read
15.20 Digital I/O read word
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range 0 to 255
Update rate Background write
Binary value for xx Digital I/O
1
2
4
8 Terminal T5
16 Terminal T6
32 Terminal T7
64 Terminals T8 & T9
128
15.21 to 15.23 Unused parameters
