Control Techniques Commander SK User Manual

Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
Menu 9
Commander SK Advanced User Guide 97
Issue Number: 2 www.controltechniques.com
Menu 9 contains two programmable logic block functions (which can be used to produce any type of 2 input logic gate, with or without a delay), a
motorised potentiometer function and a binary sum block.
The programmable logic functions are active only if both the sources are routed to a valid parameter.
The motorised potentiometer or binary sum functions are only active if the output destination is routed to a valid unprotected parameter. If only the
indicator parameter is required, the destination parameter should be routed to an unused valid parameter.
Indicates the output state of the programmable logic function. The output of the logic function can be routed to the digital output if required, by setting
the appropriate digital output source in menu 8.
This source parameter and Pr 9.14 define the inputs for source 1 of the programmable logic functions.
Only bit parameters can be programmed into these inputs.
If one or both inputs to the logic function are invalid, then the logic output will always be 0.
Setting this parameter and Pr 9.15 to a 1 causes the input sense of the logic functions to be inverted.
This source parameter and Pr 9.16 defines the inputs for source 2 of the programmable logic functions.
Only bit parameters can be programmed into these inputs.
If one or both inputs to the logic function are invalid, then the logic output will always be 0.
9.01 Logic function 1 output indicator
9.02 Logic function 2 output indicator
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0 or 1
Update rate 21 ms
9.03 Motorised pot output
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1 1
Range ±100.0 %
Update rate 21 ms
9.04 Logic function 1 source 1
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range Pr 0.01 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
9.05 Logic function 1 source 1 invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 or 1
Default 0
Update rate 21 ms
9.06 Logic function 1 source 2
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range Pr 0.01 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
NOTE
