Control Techniques Commander SK User Manual

Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
Menu 15
Commander SK Advanced User Guide 153
Issue Number: 2 www.controltechniques.com
In modes 2 and 3, a current loop loss trip (cL) will be generated if the current input falls below 3mA.
If 4-20 or 20-4 modes are selected and the drive trips on current loop loss (cL), analog reference 2 cannot be selected if the current reference is less
then 3mA.
If 4-.20 or 20-.4 modes are selected, Pr 15.03 will switch from a 0 to 1 to indicate that the current reference is less then 3mA.
Terminal T3 is a voltage/current output. The setting of this parameter configures the terminal for the required mode.
This parameter displays the level of the analog signal present at analog input 1.
In voltage mode, this is a bipolar voltage input where the input range is -10V to +10V.
In current mode, this is a unipolar current input having a maximum measurable input of 20mA. The drive can be programmed to convert the measured
current to any one of the defined ranges in Pr 15.38. The selected range is converted to 0 - 100.0%.
This parameter is used to scale the analog input if so desired. However in most cases it is not necessary as each input is automatically scaled such
that for 100.0%, the destination parameters (defined by the settings of Pr 15.43) will be at maximum.
Value Display Function
0 0-20 0 to 20mA
1 20-0 20 to 0mA
2 4-20 4 to 20mA with trip on loss
3 20-4 20 to 4mA with trip on loss
4 4-.20 4 to 20mA with no trip on loss
5 20-.4 20 to 4mA with no trip on loss
6 VoLt -10 to +10 volts
15.39 Analog output 1 mode (Terminal T3)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 4
Default 0
Update rate Background read
Value Display Function
0 0-20 0 to 20mA
1 20-0 20 to 0mA
2 4-20 4 to 20mA
3 20-4 20 to 4mA
4 VoLt 0 to +10V
15.40 Analog input 1 monitor (Terminal T2)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1
Range -100% to +100%
Update rate Background write
15.41 Analog input 1 scaling (Terminal T2)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range 0.000 to 4.000
Default 1.000
Update rate Background read
NOTE
