134 Commander SK Advanced User Guide
www.controltechniques.com Issue Number: 2
Defines the destination parameters for the variable selector outputs.
Indicates the level of output signal from the variable selector.
Can be used to scale the source 1 inputs of the variable selectors.
Can be used to scale the source 2 inputs of the variable selectors.
The control parameter can be used to input a value when modes 6, 7 and 9 of the variable selector are implemented. See Pr 12.10 on page 131 and
Pr 12.30 on page 133 for variable selector modes.
12.31 Variable selector 2 destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 1.01 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
12.32 Variable selector 2 output
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range ±100.0 %
Update rate 21 ms
12.33 Variable selector 2 source 1 scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range ±4.000
Default 1.000
Update rate 21 ms
12.34 Variable selector 2 source 2 scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range ±4.000
Default 1.000
Update rate 21 ms
12.35 Variable selector 2 control
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2111
Range 0.00 to 99.99
Default 0.00
Update rate Background
12.36 to 12.39 Unused parameters
To Next Page
