1rEAd
Parameters can only be read from the SmartStick when the drive is disabled or tripped. If the drive is not in one of these states when a read is
commanded, the display will flash FAIL twice and then Pr 11.42 will be set back to no. Immediately after a read takes place, Pr 11.42 is set back to no
by the drive. Once parameters are read from the SmartStick the drive automatically performs a parameter save to it’s internal EEPROM.
2Prog
Parameters can be written to the SmartStick at any time. When a ‘Prog’ is commanded, the SmartStick is updated with the current parameter set.
Pr 11.42 is set back to no prior to the write taking place. If the card is read only the display will flash FAIL twice and then Pr 11.42 will be set back to
no.
3boot
Mode 3 is similar to mode 2 except that Pr 11.42 is not reset to 0 before the write takes place. If the ‘boot’ mode is stored in the cloning card this
makes the cloning the master device. When a drive is powered up it always checks for a SmartStick, if one is fitted and it has been programmed in
‘boot’ mode the parameters are automatically loaded from the cloning card to the drive and furthermore they are saved in the drive. This provides a
very fast and efficient way of re-programming a number of drives. Once a card is set to boot it becomes read only. If the card is read only the display
will flash FAIL twice and then Pr 11.42 will be set back to no.
Different drive ratings
The SmartStick can be used to copy parameters between drives with different ratings but certain rating dependant parameters are not copied to the
cloned drive, but are still stored within the cloning key.
If the data is transferred to a drive of a different voltage or current rating from the source drive all parameters with the RA coding bit set are not
modified and a C.rtg trip occurs.
Modes 1 and 2 are not saved to EEPROM or to the cloning card.
If this parameter is set to a non-zero value and the drive is reset when the drive is inactive, the selected default parameters will automatically be
loaded. After the parameters have been set to default values they are automatically saved to the drive’s internal EEPROM. If the drive is active the
display will flash FAIL twice and then Pr 11.43 will be set back to no.
This read write parameter defines the level of security for menu 0.
Parameter number Function
2.08 Standard ramp voltage
4.07, 21.29 Current limits
5.07, 21.07 Motor rated currents
5.09, 21.09 Motor rated voltages
5.17, 21.12 Stator resistances
5.18 Switching frequency
5.23, 21.13 Voltage offsets
5.24, 21.14 Transient inductances
6.06 DC injection braking current
11.43 Load defaults
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0 (no), 1 (Eur), 2 (USA)
Default 0 (no)
Update rate Actioned on exit of edit mode and on drive reset
Value Display Function
0 no No action
1 Eur Load European defaults
2 USA Load USA defaults
11.44 Security status
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 1 1111
Range 0 (L1), 1 (L2), 2 (L3), 3 (Loc)
Default 0 (L1)
Update rate Actioned on exit of edit mode and on drive reset
NOTE
