Menu 15 Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
154 Commander SK Advanced User Guide
www.controltechniques.com Issue Number: 2
This parameter can be used to invert the analog input reference (i.e. multiply the input scaling result by -1)
Only non-bit parameters that are not protected can be controlled by analog inputs. If a non-valid parameter is programmed to the destination of an
analog input, the input is not routed anywhere. After a modification to this parameter, the destination is only changed when a reset is performed.
This parameter may be routed to any non-protected drive parameter.
After a modification to this parameter, the destination is only changed when a reset is performed.
15.42 Analog input 1 invert (terminal T2)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 1
Default 0
Update rate Background read
15.43 Analog input 1 destination (Terminal T2)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2 1111
Range Pr 1.01 to Pr 21.51
Default Pr 0.00
Update rate Drive read on reset
15.44 Maximum drive encoder reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 32000 rpm
Default 1500
Update rate Background read
15.45 Drive encoder reference scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3111
Range 0.000 to 4.000
Default 1.000
Update rate Background read
15.46 Drive encoder reference monitor
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1
Range -100% to +100%
Update rate Background write
15.47 Drive encoder reference destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 1.01 to Pr 21.51
Default Pr 0.00
Update rate Drive read on reset
