9 Advanced parameter descriptions
9.1 Overview
Table 9-1 Menu descriptions
*Only appears when an I/O option module is fitted to the Commander SK.
Table 9-2 gives a full key of the coding which appears in the following parameter tables.
Table 9-2 Key to parameter coding
Menu no. Description
1 Frequency / speed reference
2Ramps
3 Slave frequency, speed feedback and speed control
4 Current control
5 Motor control
6 Sequencer and clock
7 Analog I/O
8 Digital I/O
9 Programmable logic, motorised pot and binary sum
10 Status and trips
11 General drive set-up
12 Threshold detectors and variable selectors
14 User PID controller
15* I/O option parameters
18 Application menu 1
20 Application menu 2
21 Second motor parameters
Coding Attribute
Bit 1 bit parameter
SP Spare: not used
FI
Filtered: some parameters which can have rapidly changing
values are filtered when displayed on the drive keypad for
easy viewing.
DE
Destination: indicates that this parameter can be a
destination parameter.
Txt Text: the parameter uses text strings instead of numbers.
VM Variable maximum: the maximum of this parameter can vary.
DP
Decimal place: indicates the number of decimal places used
by this parameter.
ND
No default: when defaults are loaded (except when the drive
is manufactured or on EEPROM failure) this parameter is not
modified.
RA
Rating dependant: this parameter is likely to have different
values and ranges with drives of different voltage and current
ratings. These parameters are not transferred by SmartStick
when the rating of the destination drive is different from the
source drive.
NC
Not cloned: not transferred to or from SmartStick during
cloning.
NV Not visible: not visible on the keypad.
PT Protected: cannot be used as a destination.
US
User save: saved in drive EEPROM when the user initiates a
parameter save.
RW Read/write: can be written by the user.
BU
Bit default one/unsigned: Bit parameters with this flag set to
one have a default of one (all other bit parameters have a
default of zero. Non-bit parameters are unipolar if this flag is
one.
PS
Power-down save: automatically saved in drive EEPROM at
power-down.
