9.11 Menu 10: Status logic and diagnostic information
Table 9-12 Menu 10 parameters: single line descriptions
Parameter Range Default Setting Update Rate
10.01 Drive healthy 0 or 1
B
10.02 Drive active 0 or 1
B
10.03 Zero speed 0 or 1
B
10.04 Running at or below minimum speed 0 or 1
B
10.05 Below set speed 0 or 1
B
10.06 At speed 0 or 1
B
10.07 Above set speed 0 or 1
B
10.08 Load reached 0 or 1
B
10.09 Drive output is at current limit 0 or 1
B
10.10 Regenerating 0 or 1
B
10.11 Dynamic brake active 0 or 1
B
10.12 Braking resistor alarm 0 or 1
B
10.13 Direction commanded 0 or 1
B
10.14 Direction running 0 or 1
B
10.15 Mains loss 0 or 1
B
10.16 Not used
10.17 Overload alarm 0 or 1 B
10.18 Drive temperature alarm 0 or 1
B
10.19 General drive alarm 0 or 1
B
10.20 Last trip {55} 0 to 230
On drive trip
10.21 Trip 1 {56} 0 to 230
On drive trip
10.22 Trip 2 {57} 0 to 230
On drive trip
10.23 Trip 3 {58} 0 to 230
On drive trip
10.24 Trip 4 0 to 230
On drive trip
10.25 Trip 5 0 to 230
On drive trip
10.26 Trip 6 0 to 230
On drive trip
10.27 Trip 7 0 to 230
On drive trip
10.28 Trip 8 0 to 230
On drive trip
10.29 Trip 9 0 to 230
On drive trip
10.30 Full power braking time 0.00 to 320.00 s 0.0 B
10.31 Full power braking period 0.0 to 1500.0 s 0.0 B
10.32 External trip 0 or 1 0 B
10.33 Drive reset 0 or 1 0 21 ms
10.34 No. of auto reset attempts 0 to 5 0 B
10.35 Auto reset delay 0.0 to 25.0 s 1.0 B
10.36 Hold ‘drive healthy’ until last attempt 0 or 1 0 B
10.37 Action on trip detection 0 to 3 0 B
10.38 User trip 0 to 255 0 B
10.39 Braking energy overload accumulator 0.0 to 100.0%
B
10.40 Status word 0 to 32767
B
