Control Techniques Commander SK User Manual

Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
Menu 14
Commander SK Advanced User Guide 143
Issue Number: 2 www.controltechniques.com
If Pr 14.18 = 0, the upper limit (Pr 14.13) defines the maximum positive output for the PID controller and the lower limit (Pr 14.14) defines the
minimum positive or maximum negative output. If Pr 14.18 = 1, the upper limit defines the maximum positive or negative magnitude for the PID
controller output. When any of the limits are active the integrator is held.
The PID output is scaled by this parameter before being added to the main reference. After the addition to the main reference, the output is
automatically scaled again to match the range of the destination parameter.
The destination parameter should be set up with the parameter that the PID controller is to control. Only non-bit parameters which are not protected
can be controlled by the PID function. If a non valid parameter is programmed the output is not routed anywhere. If the PID is to control speed then it
is suggested that one of the preset speed parameters is entered here.
When this parameter is set to 0 the integrator operates normally. Setting this parameter to 1 will cause the integrator value to be held as long as the
PID is enabled when the drive is disabled. Setting this parameter does not prevent the integrator from being reset to zero if the PID controller is
disabled.
See Pr 14.13 and Pr 14.14 on page 143.
This parameter monitors the main reference input of the PID controller.
14.14 PID low limit
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range ±100.0 %
Default -100.0
Update rate 21 ms
14.15 PID scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 1111
Range 0.000 to 4.000
Default 1.000
Update rate 21 ms
14.16 PID output destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 1.01 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
14.17 Hold integrator
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 or 1
Default 0
Update rate 21 ms
14.18 Select symmetrical limit on PID
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 or 1
Default 0
Update rate 21 ms
14.19 Main reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1
Range ±100.0 %
Update rate 21 ms
