If analog input 1 is programmed in any of the modes 2 to 5 (see Pr 7.06 on page 82) then this bit is set if the current input falls below 3mA. This bit can
be designated to a digital output to indicate that the current input is less than 3mA.
An offset can be added to each analog input with a range from -100% to 100%. If the sum of the input and the offset exceeds ±100% the results is
limited to ±100%.
This offers a simple control of Pr 7.19 to change the analog output. Its function is used to set the value of Pr 7.19 between a frequency output, load
output, current output, or power output, or to leave the value unchanged. A user wishing to change the analog output to something other than these
must first program this parameter to USEr (or 4).
7.28 Current loop loss indicator
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0 or 1
Update rate 5 ms
7.29 Unused parameter
7.30 Analog input 1 offset
7.31 Analog input 2 offset
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range ±100.0 %
Default 0.0
Update rate 5 ms
7.32 Unused parameter
7.33 Analog output control (Terminal B1)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 4
Default 0
Update rate Read on drive reset
Pr 7.33 Display Function Pr 7.19
0 Fr Frequency output Pr 2.01
1 Ld Load output Pr 4.02
2 A Current output Pr 4.01
3 Por Power output Pr 5.03
4 USEr Allows Pr 7.19 to be set up by user.
0Fr
Frequency output, Pr 7.19 = Pr 2.01 (
Post ramp reference)
0V represents 0Hz/0rpm
+10V represents the value of Pr 1.06 (
Maximum set speed clamp)
1Ld
Load output, Pr 7.19 = Pr 4.02 (
Active current)
2A0 to 200% output current = 0 to 10V
3Por
Where: I
max
= 150% of drive rated current
V
out
Active current
1.5 Drive rated active current
×
---------------------------------------------------------------------------------------
10×=
10V
3I
max
× Pr 5.09×
1000
---------------------------------------------------=
