9.4 Menu 3: Speed sensing thresholds and frequency input and output
Table 9-5 Menu 3 parameters: single line descriptions
Parameter Range Default Setting Update Rate
3.01 Not used
3.02 Not used
3.03 Not used
3.04 Not used
3.05 Zero speed threshold 0.0 to 20.0 Hz 1.0 BR
3.06 At speed window 0.0 to 20.0 Hz 1.0 BR
3.07 Not used
3.08 Not used
3.09 Not used
3.10 Not used
3.11 Not used
3.12 Not used
3.13 Not used
3.14 Not used
3.15 Not used
3.16 Not used
3.17 Frequency output or PWM output scaling 0.000 to 4.000 1.000 BR
3.18 Maximum output frequency 0 to 3 2 B
3.19 Not used
3.20 Not used
3.21 Not used
3.22 Hard frequency reference ±1500.0 Hz 0.0 128 ms
3.23 Hard frequency reference selector 0 or 1 0 5 ms
3.24 Not used
3.25 Not used
3.26 Not used
3.27 Not used
3.28 Not used
3.29 Position 0 to 9999 B
3.30 Not used
3.31 Not used
3.32 Position counter reset 0 or 1 0 B
3.33 Position scaling numerator 0.000 to 1.000 1.000 B
3.34 Position scaling denominator 0.0 to 100.0 1.0 B
3.35 Not used
3.36 Not used
3.37 Not used
3.38 Not used
3.39 Not used
3.40 Not used
3.41 Not used
3.42 Not used
3.43 Maximum reference frequency 0.0 to 50.0 kHz 10.0 B
3.44 Frequency reference scaling 0.000 to 4.000 1.000 B
3.45 Frequency reference 0.0 to 100.0% 5 ms
