Indication of the reference being used by the drive for system setup and fault finding.
Indication of the reference being used by the drive for system setup and fault finding.
See Pr 1.09 on page 25.
Reference used for jogging. See section 9.7 Menu 6: Drive sequencer and clock for details on when the jog mode can be activated.
This parameter is a symmetrical limit on both directions of rotation.
Defines drive absolute maximum frequency reference. Slip compensation and current limit can increase the motor frequency further.
1.01 Frequency reference selected
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11111
Range ±1500.0 Hz
Update rate 5ms
1.02 Pre-skip filter reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11111
Range ±1500.0 Hz
Update rate 5ms
1.03 Pre-ramp reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11111
Range ±1500.0 Hz
Update rate 5ms
1.04 Reference offset
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 11
Range ±1500.0 Hz
Default 0.0
Update rate 5ms
1.05 Jog reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0.0 to 400.0 Hz
Default 1.5
Update rate 5ms
1.06 Maximum set speed
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0.0 to 1500.0 Hz
Default
EUR: 50.0
USA: 60.0
Second motor
parameter
Pr 21.01
Update rate Background
