Danfoss VLT AutomationDrive Programming Guide

13-52 SL Controller Action
Array [20]
Option: Function:
[2] Select set-up
1
Select set-up 1 [2] - changes the active set-
up (0-10 Active Set-up) to ‘1’.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a serial communi-
cation bus.
[3] Select set-up
2
Select set-up 2 [3] - changes the active set-
up 0-10 Active Set-up) to ‘2’.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a serial communi-
cation bus.
[4] Select set-up
3
Select set-up 3 [4] - changes the active set-
up (0-10 Active Set-up) to ‘3’.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a serial communi-
cation bus.
[5] Select set-up
4
Select set-up 4 [5] - changes the active set-
up (0-10 Active Set-up) to ‘4’.
If the set-up is changed, it will merge with
other set-up commands coming from either
the digital inputs or via a serial communi-
cation bus.
[10] Select preset
ref 0
Select preset reference 0 [10] – selects preset
reference 0.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[11] Select preset
ref 1
Select preset reference 1 [11] – selects preset
reference 1.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[12] Select preset
ref 2
Select preset reference 2 [12] – selects preset
reference 2.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[13] Select preset
ref 3
Select preset reference 3 [13] – selects preset
reference 3.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
13-52 SL Controller Action
Array [20]
Option: Function:
[14] Select preset
ref 4
Select preset reference 4 [14] – selects preset
reference 4.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[15] Select preset
ref 5
Select preset reference 5 [15] – selects preset
reference 5.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[16] Select preset
ref 6
Select preset reference 6 [16] – selects preset
reference 6.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[17] Select preset
ref 7
Select preset reference 7 [17] - selects preset
reference 7.
If the active preset reference is changed, it
will merge with other preset reference
commands coming from either the digital
inputs or via a serial communication bus.
[18] Select ramp 1
Select ramp 1 [18] - selects ramp 1.
[19] Select ramp 2
Select ramp 2 [19] - selects ramp 2.
[20] Select ramp 3
Select ramp 3 [20] - selects ramp 3.
[21] Select ramp 4
Select ramp 4 [21] - selects ramp 4.
[22] Run
Run [22] - issues a start command to the
Adjustable frequency drive.
[23] Run reverse
Run reverse [23] - issues a start reverse
command to the Adjustable frequency
drive.
[24] Stop
Stop [24] - issues a stop command to the
Adjustable frequency drive.
[25] Qstop
Q stop [25] - issues a quick stop command
to the Adjustable frequency drive.
[26] Dcstop
Dcstop [26] - issues a DC stop command to
the Adjustable frequency drive.
[27] Coast
Coast [27] - the Adjustable frequency drive
coasts immediately. All stop commands
including the coast command stop the SLC.
[28] Freeze output
Freeze output [28] - freezes the output
frequency of the Adjustable frequency
drive.
Parameter Descriptions FC 300 Programming Guide
MG33MD22 - VLT
®
is a registered Danfoss trademark 3-125
3
3
