13-52 SL Controller Action
Array [20]
Option: Function:
[29] Start timer 0
Start timer 0 [29] - starts timer 0, see
13-20 SL Controller Timer for further
description.
[30] Start timer 1
Start timer 1 [30] - starts timer 1, see
13-20 SL Controller Timer for further
description.
[31] Start timer 2
Start timer 2 [31] - starts timer 2, see
13-20 SL Controller Timer for further
description.
[32] Set digital out
A low
Set digital output A low [32] - any output
with SL output A will be low.
[33] Set digital out
B low
Set digital output B low [33] - any output
with SL output B will be low.
[34] Set digital out
C low
Set digital output C low [34] - any output
with SL output C will be low.
[35] Set digital out
D low
Set digital output D low [35] - any output
with SL output D will be low.
[36] Set digital out
E low
Set digital output E low [36] - any output
with SL output E will be low.
[37] Set digital out
F low
Set digital output F low [37] - any output
with SL output F will be low.
[38] Set digital out
A high
Set digital output A high [38] - any output
with SL output A will be high.
[39] Set digital out
B high
Set digital output B high [39] - any output
with SL output B will be high.
[40] Set digital out
C high
Set digital output C high [40] - any output
with SL output C will be high.
[41] Set digital out
D high
Set digital output D high [41] - any output
with SL output D will be high.
[42] Set digital out
E high
Set digital output E high [42] - any output
with SL output E will be high.
[43] Set digital out
F high
Set digital output F high [43] - any output
with SL output Fwill be high.
[60] Reset Counter
A
Reset Counter A [60] - resets Counter A to
zero.
[61] Reset Counter
B
Reset Counter B [61] - resets Counter B to
zero.
[70] Start timer 3
Start Timer 3 [70] - Start Timer 3, see
13-20 SL Controller Timer for further
description.
[71] Start timer 4
Start Timer 4 [71] - Start Timer 4, see
13-20 SL Controller Timer for further
description.
13-52 SL Controller Action
Array [20]
Option: Function:
[72] Start timer 5
Start Timer 5 [72] - Start Timer 5, see
13-20 SL Controller Timer for further
description.
[73] Start timer 6
Start Timer 6 [73] - Start Timer 6, see
13-20 SL Controller Timer for further
description.
[74] Start timer 7
Start Timer 7 [74] - Start Timer 7, see
p13-20 SL Controller Timer for further
description.
Parameter Descriptions FC 300 Programming Guide
3-126 MG33MD22 - VLT
®
is a registered Danfoss trademark
3
3
