[121] Remote
reference
active
Output is high when 3-13 Reference Site =
Remote [1] or Linked to hand/auto [0]
while the LCP is in [Auto on] mode. See
above.
[122] No alarm Output is high when no alarm is present.
[123] Start command
active
Output is high when there is an active
Start command (i.e., via digital input bus
connection or [Hand on] or [Auto on]),
and no Stop or Start command is active.
[124] Running
reverse
Output is high when the Adjustable
frequency drive is running counter
clockwise (the logical product of the
status bits ‘running’ AND ‘reverse’).
[125] Drive in hand
mode
Output is high when the Adjustable
frequency drive is in [Hand on] mode (as
indicated by the LED light above [Hand
on]).
[126] Drive in auto
mode
Output is high when the Adjustable
frequency drive is in [Hand on] mode (as
indicated by the LED above [Auto on]).
[151] ATEX ETR cur.
alarm
Selectable if 1-90 Motor Thermal Protection
is set to [20] or [21]. If the alarm 164
ATEX ETR cur.lim.alarm is active, the
output will be 1.
[152] ATEX ETR freq.
alarm
Selectable if 1-90 Motor Thermal Protection
is set to [20] or [21]. If the alarm 166
ATEX ETR freq.lim.alarm is active, the
output will be 1.
[153] ATEX ETR cur.
warning
Selectable if1-90 Motor Thermal Protection
is set to [20] or [21]. If the alarm 163
ATEX ETR cur.lim.warning is active, the
output will be 1.
[154] ATEX ETR freq.
warning
Selectable if 1-90 Motor Thermal Protection
is set to [20] or [21]. If the warning 165
ATEX ETR freq.lim.warning is active, the
output will be 1.
[188] AHF Capacitor
Connect
The capacitors will be turned on at 20%
(hysteresis of 50% gives an interval of
10%–30%). The capacitors will be discon-
nected below 10%. The off delay is 10 s
and will restart if the nominal power goes
above 10% during the delay. 5-80 AHF
Cap Reconnect Delay is used to guarantee
a minimum off-time for the capacitors.
[189] External fan
control
The internal logics for the internal fan
control is transferred to this output to
make it possible to control an external
fan (relevant for HP duct cooling).
5-30 Terminal 27 Digital Output
Option: Function:
[0] * No operation
Functions are described under 5-3* Digital
Outputs
5-31 Terminal 29 Digital Output
Option: Function:
[0] * No operation
Functions are described under 5-3* Digital
Outputs
This parameter only applies to FC 302
5-32 Term X30/6 Digi Out (MCB 101)
Option: Function:
[0] * No operation This parameter is active when
option module MCB 101 is
mounted in the Adjustable
frequency drive. Functions are
described under 5-3* Digital
Outputs
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable / no warning
[5] Running
[6] Running / no warning
[7] Run in range/no warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[22] Ready,no thermal W
[23] Remote,ready,no TW
[24] Ready, Voltage OK
[25] Reverse
[26] Bus OK
[27] Torque limit & stop
[28] Brake, no brake war
[29] Brake ready, no fault
[30] Brake fault (IGBT)
[31] Relay 123
[32] Mech brake ctrl
[33] Safe stop active
[38] Motor feedback error
[39] Tracking error
[40] Out of ref range
[41] Below reference, low
[42] Above ref, high
