DEVICE DETAILS
PRODUCT REFERENCE GUIDE 87
Decoder Name
Identifies the type of decoder. For example, BLR_VL5.10.56R_LNX or EVL 1.1.24.2 (VL
VL5.11.00U.50331646.10)
Controller Mode
Displays the mode of the camera; Active Controller, Backup Controller or Client.
Host Port IP Address
The Internet Protocol address (IP address) of the host port.
Image Port IP Address
The Internet Protocol address (IP address) of the image port.
Configuration Update Count
The number of times the configuration file has been updated.
Diagnostic Messages
Displays any diagnostic messages that apply. Click on Diagnostics Messages to access the
complete list of possible messages.
Real Time Processor (RTP) Details
Online Indicator
Green = Online (connected and recognized in the cluster)
Gray = Unit not connected (unit not seen by master)
Yellow = Online but not assigned to the cluster (shown under Cameras not in this Cluster)
Red = Offline
Status Indicator
Green = Online (connected and recognized in the cluster)
Gray = Unit not connected (unit not seen by master)
Yellow = Online but not assigned to the cluster (shown under Cameras not in this Cluster)
Red = Offline
IP Address
This is the SYNC IP address provided from the DHCP controller in the cluster.
MAC Address
A media access control address (MAC address) of a device is a unique identifier assigned to a
network interface controller (NIC) for communications at the data link layer of a network
segment.
Software Type
Describes the type of software on the device. Typically this will indicate STANDARD or a
customer name if your software is custom.
Software Version
Identifies the version number of the software
FPGA Version
The version of the Datalogic field-programmable gate array (FPGA).
My Decoder’s MAC
A media access control address (MAC address) of a device is a unique identifier assigned to a
network interface controller (NIC) for communications at the data link layer of a network
segment.
My Decoder’s IP
Datalogic Technical Support will use these Diagnostic messages to properly diagnose
and troubleshoot your cameras.
Since the Real Time Processor is a sub-processor to the Decoder software, the My
Decoder’s MAX and the My Decoder IP identify the Decoder processor that they are
related to.
