Delta AH500 User Manual

Chapter 7 High-speed Counter Module AH02HC/AH04HC
7-5
Item Specifications
Specifications
Maximum
frequency of
counting
The maximum frequency is 200 kHz.
Range
The number of sampled pulses is in the range of -200000 to
200000.
The number of accumulated pulses is in the range of
-999999999 to 999999999.
The number of input pulses is in the range of -2147483648 to
2147483648.
Type
Linear count
Circular count
RESET input
Input
(differential
signal)
CH0: X0.0+ and X0.0-
CH1: X0.1+ and X0.1-
CH2: X0.2+ and X0.2-
CH3: X0.3+ and X0.3-
Signal level
5~24 V DC
Maximum
current
15 mA
Comparison
output
Output type
Channel 0: The high-speed pulse output Y0.8 is a transistor
whose collector is an open collector.
Channel 1: The high-speed pulse output Y0.9 is a transistor
whose collector is an open collector.
Channel 2: The high-speed pulse output Y0.10 is a transistor
whose collector is an open collector.
Channel 3: The high-speed pulse output Y0.11 is a transistor
whose collector is an open collector.
Signal level
24 V DC
Maximum
current
15 mA
7.2.5 Functions of AH02HC-5A/AH04HC-5A
Function Description
Enabling/Disabling a count
1. Users can enable or disable a channel.
2. If unnecessary channels are disabled, the internal
operation will become more efficient.
Accumulation
counter
Linear count
The number of accumulated pulses is in the range of
-999999999 to 999999999. If the number of accumulated
pulses is not within the range, the overflow flag will be
turned ON.
Circular
count
The number of accumulated pulses is in the range of
-999999999 to 0, or in the range of 0 to 999999999.
Comparison
If the number of accumulated pulses meets the comparison
condition set, the comparison flag will be turned ON, and a
signal will be output. Users can reset the comparison
condition.
Sampling
counter
Setting a
cycle
Users can change the cycle of updating the number of
sampled pulses or the cycle of updating the number of
accumulated pulses.
Averaging
the number
of sampled
pulses
The number of sampled pulses is divided by the number of
cycles set by users.
Prescaling
The number of input pulses is multiplied by a scale.
