Chapter 9 Ethernet Communication Module AH10/15EN
9-19
Additional remark:
1. If the values in m
1
and m
2
exceed the range, the operation error occurs, the instruction is not
executed, SM0 is ON, and the error code in SR0 is 16#2003.
2. If S~S+n-1 exceeds the device range, the instruction is not executed, SM0 is ON, and the error
code in SR0 is 16#2003.
3. If the value in n exceeds the range, the operation error occurs, the instruction is not executed,
SM0 is ON, and the error code in SR0 is 16#200B.
4. Due to the fact that the use of the instruction TO decreases the execution efficiency of the CPU
module and that of the I/O module, users should use it less often.
5. The descriptions of the error codes:
Error code Description
16#2003
Please refer to point 1 and point 2 in the
additional remark.
16#200B
Please refer to point 3 in the additional
remark.
16#1400
An error occurs when the data is
accessed through the auxiliary
processor.
16#1401
An error occurs when the data in the I/O
module is accessed.
16#1402
The arrangement of the I/O modules is
not consistent with the module table.
16#1407
A communication error occurs when the
data is accessed through the auxiliary
processor.
9.3.5 Introduction of the IEC60870-5-104 protocol
 The IEC60870-5-104 protocol is only available for AH15EN-5A.
 The supported data type ID:
Type id
Description
M_SP_NA_1 (1) Single-point information
M_DP_NA_1 (3) Double-point information
M_ST_NA_1 (5) Step position information
M_BO_NA_1 (7) Bit string of 32 bit
M_ME_NA_1 (9) Measured value, normalized value
M_ME_NB_1 (11) Measured value, scaled value
M_ME_NC_1 (13) Measured value, short floating point value
M_IT_NA_1 (15) Integrated totals
M_PS_NA_1 (20) Packed single-point information with status change detection
M_ME_ND_1 (21) Measured value, normalized value without quality descriptor
M_SP_TB_1 (30) Single-point information with time tag CP56Time2a
M_DP_TB_1 (31) Double-point information with time tag CP56Time2a
M_ST_TB_1 (32) Step position information with time tag CP56Time2a
C_BO_NA_1 (33) Bit string of 32 bit with time tag CP56Time2a
M_ME_TD_1 (34) Measured value, normalized value with time tag CP56Time2a
M_ME_TE_1 (35) Measured value, scaled value with time tag CP56Time2a
M_ME_TC_1 (36) Measured value, short floating point value with time tag CP56Time2a
M_IT_TB_1 (37) Integrated totals with time tag CP56Time2a
M_EP_TD_1 (38) Event of protection equipment with time tag CP56Time2a
M_EP_TE_1 (39) Packed start events of protection equipment with time tag CP56time2a
M_EP_TF_1 (40) Packed output circuit information of protection equipment with time tag
CP56Time2a
C_SC_NA_1 (45) Single command
