Chapter 7 High-speed Counter Module AH02HC/AH04HC
7-9
2. An NPN encoder is used.
Shieldedcable 1*
External power supply
5~24VDC
A phase
B phase
External powersupply
5V, 1 2V, 24VDC
N
P
N
e
n
c
o
d
e
r
X0.8+
X0.8-
X0.9+
X0.9-
disable
Start
COM
+24V
OA
OB
OUT
OU T
0V 0V
+24V
Y0.8
C0
C1
04HC-5A high-speed counter module
X0.0+
X0.0-
Y0.9
Shieldedcable 1*
Shieldedcable 1*
7.3 HWCONFIG in ISPSoft
AH04HC-5A is taken for instance. If the AH500 series high-speed counter module that users use is
AH02HC-5A, it is operated in the same way as AH04HC-5A is operated.
7.3.1 Checking the Firmware Version of a Module
Users can check the firmware version of a module through HWCONFIG in ISPSoft.
(1) Start ISPSoft, and then double-click HWCONFIG in the project management area.
