Delta AH500 User Manual

AH500 Module Manual
7-8
 AH04HC-5A
Pin Termina
l
Function
Pin Terminal
Function
Count Count
1 C3 COM3 2 Y0.11 Out3
3 C2 COM2 4 Y0.10 Out2
5 C1 COM1 6 Y0.9 Out1
7 C0 COM0 8 Y0.8 Out0
9
． ．
10
． ．
11
． ．
12
． ．
13 X0.3- Rst3- 14 X0.3+ Rst3+
15 X0.15- CntB3- 16 X0.15+ CntB3+
17 X0.14- CntA3- 18 X0.14+ CntA3+
19 X0.2- Rst2- 20 X0.2+ Rst2+
21 X0.13- CntB2- 22 X0.13+ CntB2+
23 X0.12- CntA2- 24 X0.12+ CntA2+
25 X0.1- Rst1- 26 X0.1+ Rst1+
27 X0.11- CntB1- 28 X0.11+ CntB1+
29 X0.10- CntA1- 30 X0.10+ CntA1+
31 X0.0- Rst0- 32 X0.0+ Rst0+
33 X0.9- CntB0- 34 X0.9+ CntB0+
35 X0.8- CntA0- 36 X0.8+ CntA0+
7.2.9 External Wiring
1. A PNP encoder is used.
Shielded cable 1*
5 ~ 2
4
VD
C
A phase
B phase
External power supply
5V, 12V, 24VDC
PNP en
c
o
d
e
r
X0.8+
X0.8-
X0.9+
X0.9-
X0.0+
X0.0-
disable
Start
COM
+24V
OA
OB
OUT
OUT
0V
0V
+24V
Y0.8
C0
Y0.9
C1
04HC-5A high-speed counter module
Shielded cable 1*
Shielded cable 1*
External pow er su pply
