AH500 Module Manual
9-8
CR
number
Attribute Register name Description
HW LW
- #11 R/W
Triggering the setting
of the IP parameters
for port 1
0: The assignment of an IP address is complete.
1: The setting of the IP parameters (in
CR#4~CR#10) for port 1 is triggered.
- #12 R/W
Status of assigning an
IP address to port 1
0: The assignment of an IP address is complete.
1: An IP address is being assigned.
2: The assignment of an IP address by a DHCP
server has not been complete.
3: The IP parameters are incorrect.
#15 #14 R/W IP address of port 2 IP address of port 2
#17 #16 R/W Subnet mask of port 2 Subnet mask of port 2
- #20 R/W
Assigning an IP
address to port 2 by a
DHCP server
0: Static IP address
1: An IP address is assigned by a DHCP server.
- #21 R/W
Triggering the setting
of the IP parameters
for port 2
0: The assignment of an IP address is complete.
1: The setting of the IP parameters (in
CR#14~CR#20) for port 2 is triggered.
- #22 R/W
Status of assigning an
IP address to port 2
0: The assignment of an IP address is complete.
1: An IP address is being assigned.
2: The assignment of an IP address by a DHCP
server has not been complete.
3: The IP parameters are incorrect.
#47 #23 Reserved
- #48 R/W
Execution state of
email 1
Execution state of email 1
- #49 R/W
Execution state of
email 2
Execution state of email 2
- #50 R/W
Execution state of
email 3
Execution state of email 3
- #51 R/W
Execution state of
email 4
Execution state of email 4
- #52 R/W
Execution state of
email 5
Execution state of email 5
- #53 R/W
Execution state of
email 6
Execution state of email 6
- #54 R/W
Execution state of
email 7
Execution state of email 7
- #55 R/W
Execution state of
email 8
Execution state of email 8
The definitions of the symbols:
R: Users can read the data from the register by means of the instruction FROM.
W: Users can write the data into the register by means of the instruction TO.
 Basic setting and functions
 CR#0: The value in CR#0 is a model code. Users can read the model code by means of a
program to judge whether the module exists.
 CR#1: The value in CR#1 represents the version of the system.
 Email functions
 CR#48~CR#55: Please refer to the following table.
Value in the control register Execution state of the email
0
The email is not sent.
1
The email is being processed.
