Delta AH500 - Page 340

AH500 Module Manual
9-10
connection
#526 R/W Connection 5 Common ASDU
Address
Common ASDU Address of the 5
th
slave connection
#528 #527 R/W Connection 6 IP Address IP address of the 6
th
slave
connection
#529 R/W Connection 6 Common ASDU
Address
Common ASDU Address of the 6
th
slave connection
#531 #530 R/W Connection 7 IP Address IP address of the 7
th
slave
connection
#532 R/W Connection 7 Common ASDU
Address
Common ASDU Address of the 7
th
slave connection
#534 #533 R/W Connection 8 IP Address IP address of the 8
th
slave
connection
#535 R/W Connection 8 Common ASDU
Address
Common ASDU Address of the 8
th
slave connection
#537 #536 R/W Connection 9 IP Address IP address of the 9
th
slave
connection
#538 R/W Connection 9 Common ASDU
Address
Common ASDU Address of the 9
th
slave connection
#540 #539 R/W Connection 10 IP Address IP address of the 10
th
slave
connection
#541 R/W Connection 10 Common
ASDU Address
Common ASDU Address of the 10
th
slave connection
#543 #542 R/W Connection 11 IP Address IP address of the 11
th
slave
connection
#544 R/W Connection 11 Common
ASDU Address
Common ASDU Address of the 11
th
slave connection
#546 #545 R/W Connection 12 IP Address IP address of the 12
th
slave
connection
#547 R/W Connection 12 Common
ASDU Address
Common ASDU Address of the 12
th
slave connection
#549 #548 R/W Connection 13 IP Address IP address of the 13
th
slave
connection
#550 R/W Connection 13 Common
ASDU Address
Common ASDU Address of the 13
th
slave connection
#552 #551 R/W Connection 14 IP Address IP address of the 14
th
slave
connection
#553 R/W Connection 14 Common
ASDU Address
Common ASDU Address of the 14
th
slave connection
#555 #554 R/W Connection 15 IP Address IP address of the 15
th
slave
connection
#556 R/W Connection 15 Common
ASDU Address
Common ASDU Address of the 15
th
slave connection
#558 #557 R/W Connection 16 IP Address IP address of the 16
th
slave
connection
#559 R/W Connection 16 Common
ASDU Address
Common ASDU Address of the 16
th
slave connection
#560 ~ #607 Reserved
#608 W Triggering the connection
1~16
Every bit represents a remote
device.
0: to disconnect the connection
1: to establish a connection
#609 Reserved
#610 R Statuses of the connection
1~16
Every bit represents a remote
device.
0: The connection is active.
1: The connection is inactive.
