Delta AH500 User Manual

AH500 Module Manual
2-18
(2) AH08AD-5B
Shielded cable*1
V0+
V0-
*2
CH0
1M
AG
1M
SLD
V7+
V7-
CH7
1M
AG
1M
SLD
CH0
*3
-10V~+10V
+
-
+24V
0V
CH7
Shielded cable*1
+24V
+
-
Example:
Position transducer or proportioning valve
-10V~+10V
Example:
Position transducer or proportioning valve
Four-wire connection: Voltage input
Three-wire connection: Voltage input
0V
*1. Please use a shielded cable as an analog input cable, and isolate the shielded cable from other power
cables.
*2. If ripple voltage results in interference with the wiring, please connect a 0.1~0.47 μF and 25 V
capacitor.
*3. Please connect the terminal SLD to the ground terminal
.
(3) AH08AD-5C
Shielded cable*1
I0+
CH0
1M
AG
1M
SLD
Shielded cable*1
I7+
I7-
CH7
1M
AG
1M
SLD
CH0
CH7
*2
I0-
250
250
-20mA~+20mA
+
-
+24V
0V
+
-
+24V
0V
Shielded cable*1
I1+
I1-
CH1
1M
AG
1M
SLD
CH1
250
+24V
+
-
-20mA~+20mA
-20mA~+20mA
Four-wire connection: Current input
Three-wire connection: Current input
Two-wire connection: Current input
0V
