Delta AH500 User Manual

AH500 Module Manual
11-108
Bit
Status value
Indication
How to deal with
Bit 5
0
AHRTU-DNET-5A runs
normally.
--
1
AHRTU-DNET-5A is in low
voltage
Check if the connection between
AHRTU-DNET-5A and the rack is
normal and the power module works.
Bit 6
Reserved
--
--
Bit 7
0
AHRTU-DNET-5A runs
normally.
--
1
The configuration data of the
hung module exceed 980 bytes.
Reduce and appropriately configure
the configuration data.
Bit 8
0
The first extension rack runs
normally.
--
1
The first extension rack is
abnormal.
Check the connection of the
extension rack or replace it with
another one.
Bit 9
0
The second extension rack runs
normally.
--
1
The second extension rack is
abnormal.
Check the connection of the
extension rack or replace it with
another one.
Bit 10
0
The third extension rack runs
normally.
--
1
The third extension rack is
abnormal.
Check the connection of the
extension rack or replace it with
another one.
Bit 11
0
The fourth extension rack runs
normally.
--
1
The fourth extension rack is
abnormal.
Check the connection of the
extension rack or replace it with
another one.
Bit 12
0
The fifth extension rack runs
normally.
--
1
The fifth extension rack is
abnormal.
Check the connection of the
extension rack or replace it with
another one.
Bit 13
0
The sixth extension rack runs
normally.
--
1
The sixth extension rack is
abnormal.
Check the connection of the
extension rack or replace it with
another one.
Bit 14
0
The seventh extension rack
runs normally.
--
1
The seventh extension rack is
abnormal.
Check the connection of the
extension rack or replace it with
another one.
Bit 15
Reserved
--
--
