IO mapping relationships between master PLC and the I/O modules connected to AHRTU-PFBS-5A
Register in master PLC
Devices connected to
AHRTU-PFBS-5A
Offset
D6000（bit0~bit7）
Y0.0~Y0.7 of 16AP 0
D6001（bit0~bit7）
Y0.0~Y0.7 of 16AP 2
D6002
Digital value that output channel 0 in
06XA corresponds to
4
D6003
Digital value that output channel 1 in
06XA corresponds to
D6004
Digital value that channel 0 in 08DA
corresponds to
8
D6005
Digital value that channel 1 in 08DA
corresponds to
D6006
Digital value that channel 2 in 08DA
corresponds to
D6007
Digital value that channel 3 in 08DA
corresponds to
D6008
Digital value that channel 4 in 08DA
corresponds to
D6009
Digital value that channel 5 in 08DA
corresponds to
D6010
Digital value that channel 6 in 08DA
corresponds to
D6011
Digital value that channel 7 in 08DA
corresponds to
D6012（bit0~bit7）
Y0.0~Y0.7 of 16AP 24
D1000（bit0~bit7）
X0.0~X0.7 of 16AP 0
D1001（bit0~bit7）
X0.0~X0.7 of 16AP 2
D1002
Digital value that input channel 0 in
06XA corresponds to
4
D1003
Digital value that input channel 1 in
06XA corresponds to
D1004
Digital value that input channel 2 in
06XA corresponds to
D1005
Digital value that input channel 3 in
06XA corresponds to
D1006（bit0~bit7）
X0.0~X0.7 of 16AP 12
