AH500 Module Manual
16-8
16.3.2 Modules Supported
 Below is the table of AH series main backplanes and extension backplanes which
AHRTU-ETHN-5A can be connected to.
Model Description
AHBP04M1-5A
4-slot main backplane exclusively used for
AHCPU5x1-EN/AHRTU-ETHN-5A
AHBP06M1-5A
6-slot main backplane exclusively used for
AHCPU5x1-EN/AHRTU-ETHN-5A
AHBP08M1-5A
8-slot main backplane exclusively used for
AHCPU5x1-EN/AHRTU-ETHN-5A
AHBP12M1-5A
12-slot main backplane exclusively used for
AHCPU5x1-EN/AHRTU-ETHN-5A
AHBP06E1-5A
6-slot extension backplane exclusively used for
AHCPU5x1-EN/AHRTU-ETHN-5A
AHBP08E1-5A
8-slot extension backplane exclusively used for
AHCPU5x1-EN/AHRTU-ETHN-5A
 Digital I/O modules
Below is the table of digital I/O modules connectable to AHRTU-ETHN-5A and corresponding
data lengths.
Digital I/O
module
I/O Data length (Unit: words)
EtherNet/IP Scanner →
AHRTU-ETHN-5A
AHRTU-ETHN-5A
→
EtherNet/IP Scanner
AH16AM10N-5A - 1
AH16AM30N-5A - 1
AH32AM10N-5A - 2
AH32AM10N-5B - 2
AH32AM10N-5C - 2
AH64AM10N-5C - 4
AH16AR10N-5A - 1
AH16AN01R-5A 1 -
AH16AN01T-5A 1 -
AH16AN01P-5A 1 -
AH16AN01S-5A 1 -
AH32AN02T-5A 2 -
AH32AN02P-5A 2 -
AH32AN02T-5B 2 -
AH32AN02P-5B 2 -
AH32AN02T-5C 2 -
AH32AN02P-5C 2 -
AH64AN02T-5C 4 -
AH64AN02P-5C 4 -
AH16AP11R-5A 1 1
AH16AP11T-5A 1 1
