3 Compare the serial number of each dSPACE board (label on each
board’s bracket) with the one shown in the Board Details property
page of the Platform/Device Manager to make sure that your
applications are still loaded to the correct dSPACE boards.
n After using the Clear System command, you must
reregister all installed dSPACE boards that do not
support plug & play or where plug & play mode is
disabled by means of the address switches.
n It is your responsibility to check and ensure that all
applications are still loaded to the correct board.
Since this is not under complete control of the
dSPACE software it might even be necessary to
change external connections to the boards! In a
subsequent release of the Platform/Device Manager
it will be possible to assign board names to the
particular boards as needed.
Problems Using an Expansion Box via Bus Connection
You should follow these guidelines when connecting the host PC to
an expansion box via a bus interface:
n When switching on the system, the expansion box should usually
be switched on first, followed by the PC.
n Do not switch off the expansion box while the PC is still running.
This might lead to unpredictable errors.
Guidelines to avoid
problems
Problems Related to the Firmware
If you are prompted to update your firmware when downloading an
application to your real‑time processor(s), refer to the Firmware
Manager Document for further information.
Firmware update
s
Hardware Problems
t
DS1103 Hardware Installation and Configuration November 2014
213
