dSPACE DS1103 User Manual

Connecting RS232 Devices
If you want to connect two DTE devices (data terminal equipment,
such as a PC), you have to cross-connect the data lines and the
handshake lines of the two RS232 devices.
To do this, connect the pins of the devices as shown below. This
method is known as 'null modem cabling'.
Guidelines
DTE: data terminal equipment
External device
or another dSPACE board
(DTE)
DS1103
(DTE)
GND GND
RI RI
CTS
RTS
RTS
CTS
DTR
DCD
DCD
DTR
DSR
DSR
TXD
RXD
TXD
RXD
s
Serial Interface
t
DS1103 Hardware Installation and Configuration November 2014
189
