Analog Outputs
The DS1103 provides a digital/analog converter (DAC) with eight
parallel DAC channels. The analog output channels are called
DACH1 ... DACH8.
Objetive
Information in this section
Hardware details
I/O Circuit and Electrical Characteristics 166
Information in other sections
Feature description
DAC Unit ( DS1103 Features)
Noise, crosstalk and inductive effects can degrade the
signal and lead to incorrect results if you do not perform
the following correctly.
Grounding and Shielding
Proper grounding and shielding reduces noise and inductive effects.
196
Reducing Crosstalk 200
Wiring Up External Devices 200
Where to go from here
s
Analog Outputs
t
DS1103 Hardware Installation and Configuration November 2014
165
