dSPACE DS1103 User Manual

Connector Signal Connector Signal
CP1 ADCH1 CP15 ADCH15
CP2 ADCH2 CP16 ADCH16
CP3 ADCH3 CP17 ADCH17
CP4 ADCH4 CP18 ADCH18
CP5 ADCH5 CP19 ADCH19
CP6 ADCH6 CP20 ADCH20
CP7 ADCH7 CP21 DACH1
CP8 ADCH8 CP22 DACH2
CP9 ADCH9 CP23 DACH3
CP10 ADCH10 CP24 DACH4
CP11 ADCH11 CP25 DACH5
CP12 ADCH12 CP26 DACH6
CP13 ADCH13 CP27 DACH7
CP14 ADCH14 CP28 DACH8
In order to avoid poor performance of the analog
subsystems, do not form ground loops within the BNC
wiring.
Pinout
Slave ADC Connector (CP29)
The slave ADC connector (CP29) is a 37-pin, male Sub-D connector
located on the front of the connector panel.
Objective
Because the pin numbering used for Sub-D connectors is not
standardized, the following figure shows the numbering scheme used
(front view).
Do not rely on the numbers written on Sub-D
connectors.
Pinout
s
Connector Pinouts and LEDs
t
130
s
DS1103 Hardware Installation and Configuration November 2014
