Matching link cables (fiber optic or crossed-over patch cable) are
delivered with the hardware package. Use only these cables.
Link cables
DS814 Data Sheet
The following table provides the technical characteristics of the
DS814 Link Board (Box):
Technical data
Parameter Specification
Slave interface 16-bit ISA slot in dSPACE expansion box
Supported link interfaces DS815, DS817, DS819, DS821, DS830
Physical connection n Crossed‑over patch cable: twisted pair (CAT5 STP)
n Fiber‑optic cable: multimode (62.5/125 μm)
Cable length per connection n Max. 10 m (crossed‑over patch cable)
n Max. 100 m (fiber‑optic cable)
Protocol High‑speed serial link (proprietary)
Max. transfer rate 100 MBit/s
1)
Power supply +5 V ±5%, 1.0 A
Physical size 158 x 80 x 18 mm (6.3 x 3.1 x 0.7 in.)
Ambient temperature 0 … 70 ºC (32 … 158 ºF)
1)
The transfer rate describes the capabilities of the hardware components and circuits of dSPACE products. Depending on the
software complexity the attainable overall performance can deviate significantly from the hardware specification.
DS815 Link Board (PC)
The DS815 (to be installed in the host PC) is a PC card and provides a
PCMCIA link to the DS814 Link Board (Box), a DS830 Multilink Panel
or MicroAutoBox. The DS815 always works in Plug & Play mode.
Objective
Information in this section
DS815 Board Overview 231
DS815 Data Sheet 233
Where to go from here
s
Accessories
t
230
s
DS1103 Hardware Installation and Configuration November 2014
