Parameter Specification
As of Board Revision
DS1103-09
Up to Board Revision
DS1103-07
Slave DSP Type Texas Instruments TMS320F240 DSP
Clock rate 20 MHz
Memory n 64Kx16 external code memory
n 28Kx16 external data memory
n 4Kx16 dual-port memory for communication
n 32 KB flash memory
I/O channels n 16 ADC inputs
n 12 PWM outputs
n 4 capture inputs
n 2 serial ports
Input voltage range n TTL input/output level
n ADC inputs: 0 … 5 V
Output current Max. ±13 mA
Host interface n Eight 16-bit I/O ports in the 64K host I/O space
n Processor/host and host/processor interrupts
n Plug-and-Play support
Physical size n 340 x 125 x 45 mm (13.4 x 4.9 x 1.77 in)
n The board requires one length PC/AT ISA slot and three
brackets
Ambient temperature 0 … 50 ºC (32 … 122 °F)
Cooling Passive cooling Active cooling by fan
Power supply n +5 V ±5 %, 4 A
n +12 V ±5 %, 0.75 A
n –12 V ±5 %, 0.25 A
n +5 V ±5 %, 6 A
n +12 V ±5 %, 0.75 A
n –12 V ±5 %, 0.25 A
CP1103 Data Sheet
The following table shows the data sheet of the CP1103 Connector
Panel.
Technical data
Parameter Specifications
Grounding The enclosure and the front panel are not grounded.
Cable length 2 m (6.6 ft) standard
Physical size (with desktop enclosure)
(length x depth x height)
433.5 x 142.5 x 70 mm (17.07 x 5.61 x 2.75 in)
s
Data Sheets
t
224
s
DS1103 Hardware Installation and Configuration November 2014
