To establish the bus interface via fiber-optic cable
N O T I C E
Bending may damage the fiber-optic cable.
n Do not bend the fiber-optic cable beyond a radius of
less than 40 mm.
1 Remove the protective caps from the connectors of the DS817 or
DS819 and DS814.
2 Remove the small protective caps from the plugs.
3 Connect the DS817 or the DS819 to the DS814.
4 Switch on the system. Refer to How to Switch On the dSPACE
System on page 41.
The dSPACE system is now ready to run real-time applications.
To check the proper installation and the board properties, and to get
started with the system, refer to the First Work Steps with a
dSPACE System document.
Next steps
HowTos
• How to Install the DS1103 on page 38
• How to Switch Off a dSPACE System on page 37
Related topics
How to Establish the DS815/DS821 <–> DS814 Bus Interface
The following instructions apply if you want to install a bus
connection with link boards DS815, DS821 and DS814.
Objective
n Use only the cables which come with the hardware package.
n DS815 Link Boards (PC) delivered before November 2001 are
equipped with other connectors. You need a matching link cable.
For details, refer to DS815 Connector and PC Card Link
on page 60.
n To connect the DS815 with a standard patch cable an adapter
cable is available from dSPACE. For details, refer to DS815-RJ45
adapter cable on page 62.
Cables
Method 2
s
Connecting via Bus Interface
t
DS1103 Hardware Installation and Configuration November 2014
59
