Resource Requirements of dSPACE Boards
Depending on the installation, dSPACE boards require resources in
the host PC and the expansion box.
Objective
Information in this section
Installation in the Host PC 31
Installation in the Expansion Box 32
Connection of MicroAutoBox to the Host PC 33
Installation in the Host PC
The following table lists the required I/O address range together with
the default address and the required memory of dSPACE boards
when installed in the host PC. Some dSPACE boards support Plug &
Play in which case they require an interrupt request line (IRQ).
However the boards operate correctly even if no free IRQ is available.
The resource requirements listed in this table apply to the
host PC.
Board Slot
Type
Required
I/O
Address
Range
Default
I/O Base
Address
Required
Memory
Range
Required
IRQ
DS1104 PCI – – 2 x 4 KB 1 (PCI)
DS1104
(PCIe
variant)
PCIe – – 2 x 4 KB 1 (PCIe)
DS815 PCMCIA 10H Plug &
Play
None 1 (ISA)
DS817 PCI 10H Plug &
Play
None 1 (PCI)
Resources in the host PC
Where to go from here
s
Resource Requirements of dSPACE Boards
t
DS1103 Hardware Installation and Configuration November 2014
31
