Parameter Specification
Mounting positions n Horizontal position (with shock mounts below)
n Vertical position
n Not allowed: upside down position
Grounding Circuit ground is connected to ground of the
backplane, which is isolated from car battery ground.
Physical size Refer to Tandem-AutoBox Dimension Drawings
on page 291.
Weight (without boards) Approx. 10.6 kg (21.2 lbs)
Ambient temperature n 0 … 55 °C (32 … 131 °F)
n –10 … 55° C (14 … 131 °F) with optional heater
1)
In a Tandem-AutoBox two fans/two heaters (if this option is used) are installed.
2)
The specification stated is valid only for one heater. Note: If you use Tandem-AutoBox with the heater option, two heaters are
installed and therefore the power consumption doubles.
Tandem-AutoBox: Ensuring Correct Operating
Temperatures
The operating temperatures of hardware devices directly affect their
life time and their functionality. To avoid shortening the life times of
the hardware components, ensure that the operating temperature of
the dSPACE system does not exceed the specified ambient
temperature, for example, due to improper installation.
Objective
s
dSPACE Expansion Boxes
t
DS1103 Hardware Installation and Configuration November 2014
289
